CXL-3120 Tx Module V1.2A

LOUD ZONER-AMPLIFIERS

Combining the traditional features of a mixer-amplifier with the functionality of a ‘zoner’ and the convenience of a multi-channel power-amplifier, these unusual products offer a one-box solution, to background/foreground music with announcements, in pubs, restaurants, retail premises and hotels. The comprehensive facilities, including connectivity to additional amplifiers and fire alarm systems, will appeal to installers in many other environments, whilst the user-friendly front panel will be understood easily by unskilled staff. Models with either two-zone with utility output or four-zone outputs are offered, either low-impedance or with 70/100V line options.

Please contact Technical Support for colour brochures.

CXL-3120 Transformer Module - 70/100V Line

The three-channel transformer module mounts within the chassis of the 36-50. Each output may be configured for 100V or 70V operation. High-pass filters at 65Hz protect the transformers and speakers connected to each output.

CXL-4160 Transformer Module - 100V Line

This four-channel, 100V-line output transformer module may be fitted internally, for feeding distributed systems. This has a shrouded screw terminal strip.

46-120 - Four zone

A 4-zone mixer amplifier that offers source selection and volume adjustment of up to six sources and two microphone inputs. 46-120 offers 120W (4 ohm), or 120W at 70/100V line output with optional internal transformer modules, per zone. Facility port connections are by way of Cat5 RJ45, allowing daisy chained configuration of up to two LM2 remote plates to the facility port, for zone 1. Additional features include individual level and/or source control from either front or remote panel, remote power-down functionality, music on-hold and separate utility output and an optional CDI-46 digital paging/RS-232/Ethernet (TCP/IP) digital control interface card for extensive system integration use.
