Spaun SMS 51203 NF Compact Multiswitch (12 Way)
SAT IF:
- The new SAT IF amplifiers assure high output levels.
Depending on the unit the max. output level according to EN 60728 - 3 differs between 102 and 108 dBµV.
- Synchronous level adjuster for Low - and High - Band (0 ? - 12dB).
- The multiswitch supports standby mode. Both the SAT IF amplifier, as well as the remote power supply of the LNB
is only active if at least one receiver provides a supply voltage to its multiswitch outlet.
- The SAT IF amplifiers have a slope correction of 6 dB.
- LNB supply voltage selectable for Quattro or QUAD LNB.Terrestrial:
- Based on a new terrestrial concept the Premium Class multiswitches are coming with a passive return path
for interactive applications (Triple Play).
- Active CATV compatible forward path including InGaP Push - Pull output stage.
- By using sharp cut - off input filter a perfect selection performance is reached:
Terrestrial / SAT > 40 dB and SAT / terrestrial > 45 dB.
- The high receiver / receiver isolation is reached by using the latest directional coupler technology
> 36dB / VHF and > 32 dB / UHF.
- Level adjuster (0 ? -12 dB) for the terrestrial forward path.Miscellaneous:
Ground clamp.
The devices are equipped with an energy - saving switched- mode power supply.SPECIFICATIONS
Frequency range 5-2200 MHZ
Inputs 4 SAT + 1 TERR
Outputs 12
Tap Loss Terr passiv 5 ... 862 MHz 18 ... 22 dB
Gain Terr aktiv 47 ... 862 MHz 5 ... 2 dB
Gain SAT-ZF 950 ... 2200 MHz -6 ... 1 dB
Output level max. 47 ... 862 MHz 88 dBµV
Output level max. 950 ... 2200 MHz 90 dBµV
Isolation Rec./Rec.: Terrestrial: / SAT: = 26 dB
Mains power supply U~ 100 ... 240 V / 50 ... 60 Hz
Power consumption Terr. active / SAT aetive 26 W
Power consumption Terr. passive / SAT active 22,5 W
Power consumption Terr. active / SAT standby 6 W
Power consumption Terr. passive / SAT standby 2,5 W
Current consumption LNB max. 500 mA
LNB remote power 400 mA
Current consumption forom each receiver 40 mA
Ambient temperature -20 ... +50 °C
Abmessungen in mm 380 x 130 x 52 -
Additional Information
- SKU:
- SMS51203NF
- weight:
- 0.00
- Brand:
- Spaun
-
