Description
6 Way Multi-Switch Premium Class
HDTV compatible
SAT-IF with slope
Terrestrial push-pull
DUO-SAT system
IF Polarity selection is controlled by remote voltage,
<14.5vV,>16vH & the 22kHz tone provided by the receiver
Return path compatible
Power consumption 26 Watts
Length 260mm
Width 130mm
Depth 52mm
Max. Out dBuV 35dB@IMA3
Frequency Range 5-862 / 950-2050
Through Loss dB: OFF-AIR: 0…-20dB SAT:-5…0dB
Noise Figure dB: OFF-AIR: 7 SAT: 6.5
Isolation dB:
Cross Talk >22
SAT/U/V/F >30
Out/Out >26 -
Additional Information
- SKU:
- SMS5602NF
- weight:
- 0.00
- Brand:
- Spaun
-
Finance
Finance block
-
Reviews
-
Downloads
SMS5602NF Spaun 6 Way Multi-Switch Premium Class
Spaun
- SMS5602NF
- 6 Way Multi-Switch Premium Class
- HDTV compatible
- SAT-IF with slope
- Terrestrial push-pull
- DUO-SAT system
- IF Polarity selection is controlled by remote voltage,
- <14.5vV,>16vH & the 22kHz tone provided by the
- receiver
- Return path compatible
- Power consumption 26 Watts
- Length 260mm
- Width 130mm
- Depth 52mm
- Max. Out dBuV 35dB@IMA3
- Frequency Range 5-862 / 950-2050
- Through Loss dB: OFF-AIR: 0…-20dB SAT:-5…0dB
- Noise Figure dB: OFF-AIR: 7 SAT: 6.5
- Isolation dB:
- Cross Talk >22
- SAT/U/V/F >30
- Out/Out >26
- Availability:
- Special Order. Delivery in 7-10 working days
- SKU:
- SMS5602NF
